SAB Automatic Fixed Volume Sampler
Part #: TBD
Get Started
Request A QuoteNot What You're Looking For?
Contact Us
Designed for thick liquids such as bauxite mud and resin bead slurry, the ISOLOK SAB liquid sampler ensures that your samples are representative of your entire process and operators are protected from potentially hazardous products
This automatic sampler is made with 316 Stainless Steel components to meet different process applications.
The ISOLOK sampler's design uses compressed air and a controller to force a plunger into up to 300 psi (20.7 bar) pressurized processes for complete representative sampling.
The ISOLOK sampler's design uses compressed air and a controller to force a plunger into up to 300 psi (20.7 bar) pressurized processes for complete representative sampling.
- This ISOLOK SAB liquid sampler has a variety of options as various materials of construction and seal materials, port closures, different container types, sampler enclosures, etc.
- The SAB sampler is available with two different sample sizes, 10 cc or 25 cc per sample cycle.
Sample volume per cycle | 10 or 25 cc |
Maximum cycle frequency | 10 strokes per minute, depending on application |
Maximum particle size | .375 in (9 mm) |
Line mounting options | MNPS thread, tri-clamp, instrument hub, bolted hub |
Materials | 316 stainless steel; other materials available |
Cylinder seals | HalarĀ®, TFE or custom |
Plunger seals | TFE, polyurethane, EPDM rubber, FFKM or custom |
Commpressed air requirement | 2 SCFM at 90 psi (.05 mĀ³/minimum at 6.2 bar) |
Dimensions | 13.19 in x 4 in (33.5 cm x 10 cm) |
Minimum hipping weight | 28 lb (12.7 kg) |
