SAE Automatic Sampler

Part #: TBD

Download Specs

Email Specs

Get Started

Request A Quote

Not What You're Looking For?

Designed for particles up to 3/4 inch (19mm), the ISOLOK SAE particle sampler ensures that your samples are representative of your entire process without degrading or shearing the sample.

This automatic sampler uses a four-inch stroke cylinder to obtain samples from heavy-walled vessels.

The ISOLOK sampler's design uses compressed air to grab a fixed amount of product at set intervals. The product is then discharged by gravity to a sample container.

The SAE powder sampler is designed to capture a 90 or 100cc sample.
The sampler is available in versatile seal options to meet your process needs.
Installation and maintenance is a breeze with the sampler's heavy duty 3-inch tri-clamp ferrule.

Sample volume per cycle	90 or 100 cc
Maximum particle size	0.75 in (19 mm)
Maximum cycle frequency	10 strokes per minute, depending on application
Materials	316 stainless steel; other materials available
Actuator seals	filled Teflon®; other materials available
Static seals	fluoroelastomer; other materials available
Plunger seals	polyurethane, EPDM rubber; other materials available
Sample temperature range	-40°F to 575°F (-40°C to 302°C), depending on seal material and duty cycle
Ambient operating temperature range	-5° to 131°F (-20° to 55°C) depending on seal material
Line mount adapter type	3 in (7.6 cm) clamp ferrule
Compressed air requirement	2 SCFM at 30 to 120 psig (2.1 to 8.3 barg)
Dimensions	18.2 in x 6.5 in (462 mm x 165 mm)
Shipping weight	29 lb (13.2 kg)
